Map of Zaragoza – Torrejón de Ardoz Oil Pipeline: Pipeline Route, Oil Terminals, Pump Station, Valve Stations

Description

The map contains the 290km 14″ Zaragoza – Torrejón de Ardoz oil pipeline, which starts from the oil terminal in Zaragoza municipality of Zaragoza province, and supplies refined oil to the oil terminal in Torrejón de Ardoz, Comunidad de Madrid.

Table of Descriptions

1 Product Details
2 Methodology
3 Files Included in This Digital Map
4 Editability of Map
5 Lifetime Free Updates
6 Scope of Use Terms

1 Product Details

• Product Name: Map of Zaragoza – Torrejón de Ardoz Oil Pipeline
• Nombre del Producto: Mapa del Oleoducto Zaragoza – Torrejón de Ardoz
• Product Type: Vector Map
• Pipeline Length: 290km
• Country: Spain
• From: Zaragoza, Zaragoza
• To: Torrejón de Ardoz, Comunidad de Madrid
• No. of Oil Terminals, Pump Station: 3
• No. of Valve Stations: 22
• Coordinate Data: Not Available
• File Formats: Adobe PDF, Adobe Illustrator
• Lifetime Updates: Supported
• Language: English



2 Methodology

The vector pipeline maps (.pdf and .ai) are created using data collected from various sources including GPS, remote sensing technology, and geographic surveys, resulting in more precise location information for pipeline stations and turning points along the pipeline route.

3 Files Included in This Digital Map

3.1 [Main Map] Zaragoza – Torrejón de Ardoz Oil Pipeline

This map includes the geographical area from the pipeline’s starting point to its end point. Its content contains the pipeline route, stations along the pipeline, and the administrative regions that the pipeline passes through.

Two file formats, .pdf and .ai (Adobe Illustrator), are included. Both of them are editable and layered. Users can show and hide a layer simply with a mouse click.

The map consists of following independent layers:

• Project Name and Legend
• Names of Posición
• Names of Water
• Names of Autonomous Communities
• Names of Provinces
• Names of Municipalities
• Posición
• Pipeline
• Water
• Borders of Autonomous Communities
• Borders of Provinces
• Borders of Municipalities
• Background Color



3.2 Spain Country Map

The country map itself doesn’t contain pipeline information. However, it serves as a platform into which our users can easily add various pipeline map plugins. With pipeline map plugins, the country map provides a perspective of the pipelines from the geographical scope of the entire nation.

The country map is an editable and layered .pdf file. It consists of following independent layers:

• Legend
• Names of Water
• Names of Countries
• Names of Autonomous Communities
• Names of Provinces
• Names of Municipalities
• Water
• Borders of Countries
• Borders of Autonomous Communities
• Borders of Provinces
• Borders of Municipalities
• Background Color



3.3 [Spain Country Map Plugin] Zaragoza – Torrejón de Ardoz Oil Pipeline

The country map plugin is a single-layered .pdf file containing the pipeline route. It can be added into the country map simply with a couple of mouse clicks. In this way, our users can assemble their own oil and gas pipeline network with other oil and gas pipeline map plugins they purchased. (Tutorial on how to add a pipeline map plugin).



4 Editability of Map:

Based on the layered digital map (.pdf and .ai), users can perform further development and modifications, including but not limited to:

• Adjusting the position of text and modifying its attributes such as font, font size, and color;
• Adjusting the position and size of icon symbols;
• Modifying the path of oil and gas pipelines to reflect changes caused by rerouting;
• Adding new pipelines and stations;
• Changing the border color and line weight of different administrative regions;
• Modifying the map background color.



5 Lifetime Free Updates:

The downloadable files of digital pipeline map are updated irregularly to reflect the relocation of pipeline, construction of new stations, removal of existing stations and changes of administrative areas.

Our users are entitled to lifetime free updates for the digital maps they purchased. To download the latest updated map, visit the product download link via “my account” page of this website.



6 Scope of Use Terms:

ARA Research and Publication holds the intellectual property rights to this map and the associated research products. This product is for internal use within the user’s organization and for citation in academic papers and publications. It is prohibited to copy, sell, disclose to any third party, or distribute this product online or offline.
