Map of Balkan Stream Gas Pipeline (Bulgaria Section): Pipeline Route, Compressor Stations, Gas Metering Station, Pig Facilities, Valve Assemblies

Description

The map contains the 487km 48″ Balkan Stream Gas Pipeline (Bulgaria Section), which receives natural gas from TurkStream Gas Pipeline at Bulgaria-Türkiye border in Bolyarovo, Yambol, and ends at Bulgaria-Serbia border in Kula, Vidin. This pipeline consists of 2 sections: the Bulgaria-Türkiye border to GMS Strandzha section and Provadiya to Bulgaria-Serbia border section. The Provadiya to Bulgaria-Serbia border section is also known as “Expansion of the gas transmission infrastructure of Bulgartransgaz EAD parallel to the north (main) gas pipeline to the Bulgarian-Serbian border” Project.

Table of Descriptions

1 Product Details
2 Methodology
3 Files Included in This Digital Map
4 Editability of Map
5 Related Upstream/Downstream Pipelines
6 Lifetime Free Updates
7 Scope of Use Terms

1 Product Details

• Product Name: Map of Balkan Stream Gas Pipeline (Bulgaria Section)
• Име На Продукта: Карта на „Балкански поток“
• Product Type: Vector Map
• Pipeline Abbreviation: Balkan Stream
• Pipeline Length: 487km
• Country: Bulgaria
• From: Bulgaria-Türkiye border in Bolyarovo, Yambol
• To: Bulgaria-Serbia border in Kula, Vidin
• No. of Compressor Stations (CS), Gas Metering Station (GMS), Pig Facilities (PF): 7
• No. of Valve Assemblies (VA): 24
• Coordinate Data: Not Available
• File Formats: Adobe PDF, Adobe Illustrator
• Lifetime Updates: Supported
• Language: English



Note: This digital map is NOT a GIS map or don’t contain coordinate data. For its GIS datasets products, click here.



2 Methodology

The vector pipeline maps (.pdf and .ai) are created using data collected from various sources including GPS, remote sensing technology, and geographic surveys, resulting in more precise location information for pipeline stations and turning points along the pipeline route.

3 Files Included in This Digital Map

3.1 [Main Map] Balkan Stream Gas Pipeline (Bulgaria Section)

This map includes the geographical area from the pipeline’s starting point to its end point. Its content contains the pipeline route, stations along the pipeline, and the administrative regions that the pipeline passes through.

Two file formats, .pdf and .ai (Adobe Illustrator), are included. Both of them are editable and layered. Users can show and hide a layer simply with a mouse click.

The map consists of following independent layers:

• Project Name and Legend
• Names of Main Stations
• Names of Line Block Valves
• Names of Water
• Names of Countries
• Names of Provinces
• Names of Municipalities
• Main Stations
• Line Block Valves
• Pipeline
• Water
• Borders of Countries
• Borders of Provinces
• Borders of Municipalities
• Background Color



3.2 Bulgaria Country Map

The country map itself doesn’t contain pipeline information. However, it serves as a platform into which our users can easily add various pipeline map plugins. With pipeline map plugins, the country map provides a perspective of the pipelines from the geographical scope of the entire nation.

The country map is an editable and layered .pdf file. It consists of following independent layers:

• Legend
• Names of Water
• Names of Countries
• Names of Provinces
• Names of Municipalities
• Water
• Borders of Countries
• Borders of Provinces
• Borders of Municipalities
• Background Color



3.3 [Bulgaria Country Map Plugin] Balkan Stream Gas Pipeline (Bulgaria Section)

The country map plugin is a single-layered .pdf file containing the pipeline route. It can be added into the country map simply with a couple of mouse clicks. In this way, our users can assemble their own oil and gas pipeline network with other oil and gas pipeline map plugins they purchased. (Tutorial on how to add a pipeline map plugin).



4 Editability of Map:

Based on the layered digital map (.pdf and .ai), users can perform further development and modifications, including but not limited to:

• Adjusting the position of text and modifying its attributes such as font, font size, and color;
• Adjusting the position and size of icon symbols;
• Modifying the path of oil and gas pipelines to reflect changes caused by rerouting;
• Adding new pipelines and stations;
• Changing the border color and line weight of different administrative regions;
• Modifying the map background color.



5 Related Upstream/Downstream Pipelines:

We also provide digital maps of following direct upstream/downstream pipelines.

Uptream Pipelines:
TurkStream Gas Pipeline

Downtream Pipelines:
Balkan Stream Gas Pipeline (Serbia Section)



6 Lifetime Free Updates:

The downloadable files of digital pipeline map are updated irregularly to reflect the relocation of pipeline, construction of new stations, removal of existing stations and changes of administrative areas.

Our users are entitled to lifetime free updates for the digital maps they purchased. To download the latest updated map, visit the product download link via “my account” page of this website.



7 Scope of Use Terms:

ARA Research and Publication holds the intellectual property rights to this map and the associated research products. This product is for internal use within the user’s organization and for citation in academic papers and publications. It is prohibited to copy, sell, disclose to any third party, or distribute this product online or offline.
